Capturing Braided Hairstyles

CAPTURING BRAIDED HAIRSTYLES

Liwen Hu, Chongyang Ma, Linjie Luo, Li-Yi Wei, Hao Li

ACM Transactions on Graphics, Proceedings of the 7th ACM SIGGRAPH Conference and Exhibition in Asia 2014, 12/2014 – SIGGRAPH ASIA 2014

[paper]   [video]   [slides]   [fast forward]   [bibtex]

Copyright © 2014 Hao Li

From fishtail to princess braids, these intricately woven structures define an important and popular class of hairstyle, frequently used for digital characters in computer graphics. In addition to the challenges created by the infinite range of styles, existing modeling and capture techniques are particularly constrained by the geometric and topological complexities. We propose a data-driven method to automatically reconstruct braided hairstyles from input data obtained from a single consumer RGB-D camera. Our approach covers the large variation of repetitive braid structures using a family of compact procedural braid models. From these models, we produce a database of braid patches and use a robust random sampling approach for data fitting. We then recover the input braid structures using a multi-label optimization algorithm and synthesize the intertwining hair strands of the braids. We demonstrate that a minimal capture equipment is sufficient to effectively capture a wide range of complex braids with distinct shapes and structures.

PAPER VIDEO

CAPTURE SESSION AT TONY’S

TALK SLIDES

SIGGRAPH 2014 FAST FORWARD
